Business productivity and efficiency is the irresistible force driving Enterprise to adopt mobile tools. The SyntegraTech PA966 was specifically designed to increase your productivity in the warehouse, on the road, or in the field - by dynamically linking data collection and host systems wirelessly.

Equipped with 36 keys, the SyntegraTech PA966 can easily toggle between full alphabetical input, functional input, or numerical input - perfect for PDA-type Mobile Computer users who want a direct way to input text or functions. Or, use the PA966’s built-in 1D bar code scanner or 2D image scanner for fast and accurate data capture. The PA966’s touch screen can be used for navigation and the input of graphical data such as sketches or signatures.

Data Collection is simple, fast and accurate. Expansion slots for WLAN or WWAN makes real world data transaction possible where you really need it - in the field. Working environments are not always perfectly lit, so the PA962 features an LCD and keypad backlight that makes anytime, anywhere operation possible. Control the keypad backlight on/off and LCD backlight contrast for power saving via a simple hot key.

The rugged PA966 can withstand 1.2 meter (4 foot) bounces off a concrete floor and is sealed to IP54 standards against water and dust. The rugged housing protects the terminal against the harsh working environment often encountered by mobile users. The double-cell battery pack provides long hours of mobile operation, uncompromised productivity, and minimal down time.

The PA966 comes equipped with both a PCMCIA Type II slot and a CF Type I/Type II slot for WWAN, WWLAN, memory, and many other uses. The PA966 communicates with a host system via USB, RS232, Bluetooth, and IrDA, or take advantage of the PA966’s built-in PCMCIA slot for WiFi and other communication options.

Despite IP54 sealing and the double-cell battery, the PA966's ergonomic design still easily fits the user's hand. Users increase productivity right from the start with minimum training thanks to the PA962's vivid 240 by 320 color display, touch screen, and the familiar Windows operating system.

INTERNAL PERFORMANCE Operating System Microsoft Windows CE 5.0 Professional Plus CPU 400Mhz Intel PXA270 Processor Memory 64 MB SDRAM / 64 MB Flash ROM

EXTERNAL CHARACTERISTICS Dimensions 7.3”H x 3.4”W x 1.7”D Weight 16 ounces Display 3.5” color QVGA (240 x 320 pixels) Backlit touch-screen, transflective TFT-LCD Heating system Keypad 36-key alphanumeric keypad, Backlit (includes function and navigation keys) Indicator LED (green/red) Audio beeper

COMMUNICATION Batch USB 1.1 RS232 Wireless Bluetooth (Class II) WWAN - PCMICIA slot (GSM / GPRS / EDGE / 2.5G) IrDA SIR 1.2 – 115 baud rate 802.11 b/g Security WEP, WPA, APA2-TKIP, AES Passkey (Bluetooth)

BATTERY & POWER Main Battery 7.4V Li-Ion 1850mAh rechargeable battery pack Battery Life 4.5-hours to 10-hours (configuration-dependant) Extended Battery 3.7V Li-Ion 120mAh Charging Time 3-hours with the charging cable or the docking station Docking Station USB, RS232 cradle Power Input 12V AC adapter

CONNECTION & EXPANSION Slots PCMCIA Type II CF Type I/II Ports RS232 Infrared

FIELD ENVIRONMENT Drop Threshold 4’ Environmental Sealing IP54: Completely sealed against dust and splashes Humidity 5% to 95% (non-condensing) Operating Temperature -4ºF to 122ºF (-20ºC to 50ºC) (configuration-dependant) Storage Temperature -4ºF to 140ºF (-20ºC to 60ºC)

INPUT DEVICES Laser Bar Code Scanner Light source 650 ± 10 nm visible laser diode Scan rate 39 ± 3 scans/second Contrast 25% absolute dark/light reflectance Scan angle 53º nominal Depth of field 5.0 mils - 2 to 5.2" 7.5 mils - 1.7 to 8.0" 10.0 mils - 1.8 to 10" 15.0 mils - 1.9 to 13" 20.0 mils - * to 20" 40.0 mils - * to 25" 55.0 mils - * to 30" * - depending on symbol width Symbologies Codabar Code 11 Code 32 Code 39 full ASCII Code 39 standard Code 93 Code 128 Delta Code EAN-8 EAN-13 EAN 128 Interleaved 2 of 5 MSI Plessey Standard 2 of 5 Toshiba Code UPC-A UPC-E 2D SCANNER / IMAGER Light Sources Red aiming LEDs @ 626nm ± 30nm Green aiming LEDs @ 526nm ± 30nm Red illumination LEDs @ 626nm ± 30nm Scan Angle ± 40° from vertical Focal Point 7" (17.8cm) Ambient Light 535 to 100,000 lux (full sunlight) Linear Symbologies Codabar Codablock F Code 39 Code 93 Code 128 EAN-8 EAN-13 EAN 128 Interleaved 2 of 5 RSS UPC-A UPC-E 2D Symbologies Aztec Aztec Mesas Code 49 Data Matrix EAN MaxiCode Micro PDF417 PDF417 QR Code UCC Composite RSS Postal Symbologies British Post Canadian Post Japanese Post KIX Post Planet Code Postnet RFID Reader (Via PCMCIA Slot) Frequency 13 to 56 MHZ Supporting Tags ISO 15693, Tag it, I-Code, I-Code SLI Reading Distance Terminal level about 1.18” to 2.75”

IN the BOX PA966 Power Supply Battery USB cable Manuals Quick Start Guide
